シマノ シマノスモールパーツ・補修部品 WHR9100C40TUFリムステッカーUT Y07K98040 SHIMANO
248
| DURA-ACE Rear Wheel WH-R9100-C40-TU-R 10/11-speed |  | |
| 番号 | 型番 | 商品名 |
| 01 | Y07E98010 | Complete Quick Release 163 mm (6-13/32") |
| Y07E98020 | Complete Quick Release 168 mm (6-5/8") | |
| 02 | Y0B198020 | Quick Release Nut |
| 03 | Y23321000 | Volute Spring |
| 04 | Y07L98010 | Complete Hub Axle |
| 05 | Y3D898030 | Hub Axle Unit |
| 06 | Y00091270 | Stainless Ball (3/16") 22 pcs. |
| 07 | Y25R98080 | Ball Retainer (3/16") |
| 08 | Y07L98020 | Left Hand Lock Bolt Unit |
| 09 | Y3DZ98060 | Complete Freewheel Body |
| 10 | Y3CN98090 | Body Fixing Bolt |
| 11 | Y3CZ12000 | Freewheel Body Washer |
| 12 | Y26D10000 | Seal Ring |
| 13 | Y4T724000 | Low Spacer (1.85 mm) |
| 14 | EWHRIMZ2F58 | Rim {21H} |
| 15 | EWHSPOKE3GB1 | Spoke Unit {Spoke (294 mm x 14 pcs. / 272 mm x 7 pcs.) / Nipple (21 pcs.)} |
| 16 | Y4SYN1000 | Nipple |
| 17 | Y4T7S5000 | Rigth Hand Spoke (294 mm) |
| 18 | Y4T7S4000 | Left Hand Spoke (272 mm) |
| 19 | Y4SY11000 | Nipple Wrench 3.75 |
| 20 | Y07K98040 | Rim Sticker Unit |
| 21 | Y4G998100 | Valve Extension Unit |
| 22 | Y8PP98060 | R55C4-A Brake Shoes (-1 mm thinner shoe) ＆ Fixing Bolts (Pair) for Carbon Rim |
