シマノ スモールパーツ・補修部品 取付ナット（前用 / 27.0mm） Y8A023200 SHIMANO
847
'
取付ナット（前用 / 27.0mm）
■ブランド： シマノ/SHIMANO
■シマノパートNo： Y8A023200
■JANコード： 4524667284963
| ULTEGRA Caliper Brake BR-6700 Silver Version BR-6700-G Glossy Grey Version |  | |
| 番号 | 型番 | 商品名 |
| 01 | Y8G698010 | Arm Bolt Unit (M6 x 17.5) |
| 02 | Y88414200 | Set Bolt (M4) |
| 03 | Y8G698020 | Front Pivot Bolt Assembly {Pivot Bolt: 52.5 mm (2-1/16") / Pivot Nut: 10.5 mm} |
| Y8G698030 | Front Pivot Bolt Assembly {Pivot Bolt: 52.5 mm (2-1/16") / Pivot Nut: 12.5 mm} | |
| Y8G698040 | Front Pivot Bolt Assembly {Pivot Bolt: 52.5 mm (2-1/16") / Pivot Nut: 18.0 mm} | |
| Y8G698050 | Front Pivot Bolt Assembly {Pivot Bolt: 52.5 mm (2-1/16") / Pivot Nut: 27.0 mm} | |
| Y8G698110 | Front Pivot Bolt Assembly {Pivot Bolt: 52.5 mm (2-1/16") / Pivot Nut: 32.0 mm} | |
| Y8G698060 | Rear Pivot Bolt Assembly {Pivot Bolt: 37.8 mm (1-1/2") / Pivot Nut: 10.5 mm} | |
| 04 | Y8G615000 | Pivot Nut (10.5 mm) for Front/Rear |
| Y8G615010 | Pivot Nut (12.5 mm) for Front | |
| Y85574310 | Pivot Nut (18.0 mm) for Front | |
| Y8A023200 | Pivot Nut (27.0 mm) for Front | |
| Y8A023210 | Pivot Nut (32.0 mm) for Front | |
| 05 | Y85850120 | Spacer-R (2 mm) |
| 06 | Y8G608000 | Lock Nut (M7) |
| 07 | Y84B98050 | Ball Retainer Unit (Φ7) |
| 08 | Y8FN10000 | Arm Spring |
| 09 | Y8G613000 | Spring Bush |
| 10 | Y8FA09000 | EC-Bolt (M4 x 10.2) |
| 11 | Y8G698120 | Cable Adjusting Bolt Unit |
| 12 | Y8G698080 | R55C3 Cartridge-Type Brake Shoe Set (Pair) for BR-6700 |
| Y8FA16000 | R55C3 Cartridge-Type Brake Shoe Set (Pair) for BR-6700-G | |
| 13 | Y8G698130 | Tire Guide |
| 14 | Y8FN98090 | R55C3 Cartridge-Type Brake Shoes & Fixing Bolts (Pair) |
| Y8FN98140 | R55C3 Cartridge-Type Brake Shoes & Fixing Bolts (Pair) for Carbon Rim | |
| 15 | Y8FA17000 | Fixing Bolt (M4 x 5.5) |
| 16 | Y8G698090 | Shoe Fixing Bolt Unit (M5 x 11.2) |
| 17 | Y8G698100 | Quick Release Assembly |
| 18 | Y8FA98110 | Quick Release Fixing Bolt (M4 x 4.8) & Washer |
| 19 | Y8F598080 | Cable Fixing Bolt (M6 x 8.5) & Plate |
