シマノ スモールパーツ・補修部品 取付ナット（前用 / 27.0mm） Y8A023100 SHIMANO
517
＠シマノスモールパーツ SHIMANO（シマノ）
'
取付ナット（前用 / 27.0mm）
■ブランド：シマノ/SHIMANO
■シマノパートNo:Y8A023100
■JANコード:4524667956020
| Caliper Brake BR-R561-S Silver Version 、BR-R561-L Black Version |  | |
| 番号 | 型番 | 商品名 |
| 01 | Y8JY98010 | Arm Bolt Unit (M6 x 26.5) |
| 02 | Y8K698040 | Front Pivot Bolt Assembly {Pivot Bolt: 50.4 mm (2") / Pivot Nut: 10.5 mm} |
| Y8K698050 | Front Pivot Bolt Assembly {Pivot Bolt: 50.4 mm (2") / Pivot Nut: 12.5 mm} | |
| Y8K698060 | Front Pivot Bolt Assembly {Pivot Bolt: 50.4 mm (2") / Pivot Nut: 18.0 mm} | |
| Y8K698070 | Front Pivot Bolt Assembly {Pivot Bolt: 50.4 mm (2") / Pivot Nut: 27.0 mm} | |
| Y8K698010 | Rear Pivot Bolt Assembly {Pivot Bolt: 35.7 mm (1-13/32") / Pivot Nut: 10.5 mm} | |
| 03 | Y85575120 | Pivot Nut (10.5 mm) for Front/Rear |
| Y85575220 | Pivot Nut (12.5 mm) for Front | |
| Y85574210 | Pivot Nut (18.0 mm) for Front | |
| Y8A023100 | Pivot Nut (27.0 mm) for Front | |
| 04 | Y85850100 | Spacer-R (2 mm) |
| 05 | Y8E604000 | Lock Nut |
| 06 | Y8FN10000 | Arm Spring |
| 07 | Y8BY08000 | Spring Guide |
| 08 | Y8JY10000 | EC-Screw (M4 x 10.2) |
| 09 | Y8K698020 | R55C3 Cartridge-Type Brake Shoe Set (Pair) for BR-R561-S |
| Y8K698030 | R55C3 Cartridge-Type Brake Shoe Set (Pair) for BR-R561-L | |
| 10 | Y8FN98090 | R55C3 Cartridge-Type Brake Shoes & Fixing Bolts (Pair) |
| 11 | Y8FA17000 | Fixing Bolt (M4 x 5.5) |
| 12 | Y8JY98080 | Shoe Fixing Bolt Unit (M5 x 11.2) |
| 13 | Y8JY98090 | Cable Adjusting Bolt (M6 x 21.6) & Clip |
| 14 | Y8BT98010 | Cable Fixing Bolt (M6 x 9) & Plate |
