シマノ スモールパーツ・補修部品 脱落防止リング Y81703000 SHIMANO
278
＠シマノスモールパーツ SHIMANO（シマノ）
'
脱落防止リング
■ブランド：シマノ/SHIMANO
■シマノパートNo:Y81703000
■JANコード:4524667360667
| SHIMANO SLX Front Disc Brake BR-M666 Brake Caliper、SM-RT67 Disc Rotor/Center Lock SM-BH90-SB Brake Hose、SM-RT86 Disc Rotor/6-Bolt |  | |
| 番号 | 型番 | 商品名 |
| 01 | Y8JA98010 | Connecting Bolt Unit |
| 02 | Y8JA98020 | Olive & Connecter Insert |
| 03 | Y8JA07000 | Cover |
| 04 | Y8H198030 | TL-BH61 Special Tool (2 pcs.) |
| 05 | Y8JA98030 | Banjo Bolt & O-Ring |
| 06 | Y8JA04000 | Banjo Bolt |
| 07 | Y8SY28000 | O-Ring |
| 08 | Y8B214000 | Bleed Nipple Cap |
| 09 | Y8CL98050 | Bleed Nipple & Seal Ring |
| 10 | Y8CL24000 | Bleed Nipple |
| 11 | Y8B511001 | O-Ring for Bleed Nipple |
| 12 | Y8DS98010 | Adapter Fixing Bolt (M6 x 18.7) & Snap Ring |
| 13 | Y8C511000 | Snap Ring |
| 14 | Y8C509020 | Adapter Fixing Bolt (M6 x 18.7) |
| 15 | Y8DB06100 | Split Pin |
| 16 | Y8KA98010 | Resin Pad (G01S) & Spring w/Split Pin |
| 17 | Y8JZ98020 | Metal Pad (G03S) & Spring w/Split Pin |
| 18 | Y8J79801A | Resin Pad (F01A) w/Fin & Spring w/Split Pin |
| 19 | Y8J79802A | Metal Pad (F03C) w/Fin & Spring w/Split Pin |
| 20 | Y8J709000 | Pad Spacer |
| 21 | Y8J712000 | Bleeding Spacer |
| 22 | Y8G498020 | Caliper Fixing Bolt Unit (M6 x 37.9) |
| 23 | Y81703000 | Snap Ring |
| 24 | Y8G498030 | Caliper Fixing Bolt Unit (M6 x 32.1) |
| 25 | Y8K998010 | Lock Ring & Washer (Standard) |
| Y8K198010 | Lock Ring & Washer (Option) | |
| 26 | Y12009230 | TL-LR15 Lock Ring Removal Tool |
| 27 | Y8J298020 | Rotor Fixing Bolt & Lock Washer |
| 28 | Y83998010 | Mineral Oil Bleed Kit (50 ml) |
