シマノ スモールパーツ・補修部品 ハブ軸組立品（軸長141mm / 玉間130mm） Y4SK98030 SHIMANO
1,738
＠シマノスモールパーツ SHIMANO（シマノ）
'
ハブ軸組立品（軸長141mm / 玉間130mm）
■ブランド：シマノ/SHIMANO
■シマノパートNo:Y4SK98030
■JANコード:4524667983927
| Rear Wheel (8/9/10-Speed) WH-R501-R 、WH-R501-A-R |  | |
| 番号 | 型番 | 商品名 |
| 01 | Y4SK98110 | Complete Quick Release 163 mm (6-13/32") Black for WH-R501 |
| Y4SK98120 | Complete Quick Release 168 mm (6-5/8") Black for WH-R501 | |
| Y4BG98220 | Complete Quick Release 163 mm (6-13/32") Silver for WH-R501-A | |
| Y4BG98230 | Complete Quick Release 168 mm (6-5/8") Silver for WH-R501-A | |
| 02 | Y4SK98030 | Complete Hub Axle 141 mm (5-9/16") |
| 03 | Y4SK98040 | Right Hand Lock Nut Unit |
| 04 | Y00091310 | Steel Ball (1/4") 18 pcs. |
| 05 | Y30K01100 | Hub Axle M10 x 141 mm (5-9/16") |
| 06 | Y4SK98060 | Left Hand Lock Nut Unit |
| 07 | Y3CR09000 | Left Hand Seal Ring |
| 08 | Y4SK98070 | Complete Freewheel Body |
| 09 | Y3BL03000 | Body Fixing Bolt |
| 10 | Y3CR08000 | Right Hand Seal Ring |
| 11 | Y4SK98080 | Freewheel Body Unit |
| 12 | Y3AN10000 | Freewheel Body Washer |
| 13 | EWHRIM2URDBC | Rim {24H / Black / Rim Sticker: Standard} |
| EWHRIM2URDBCM | Rim {24H / Black / Rim Sticker: Monotone} | |
| 14 | EWHSPOKEPB1 | Spoke Unit for WH-R501 {Spoke (286 mm x 24 pcs.) / Nipple (24 pcs.)} |
| EWHSPOKEZB1 | Spoke Unit for WH-R501-A {Spoke (286 mm x 24 pcs.) / Nipple (24 pcs.)} | |
| 15 | Y0123Z865 | Spoke (286 mm) for WH-R501 |
| Y01234865 | Spoke (286 mm/Bladed type) for WH-R501-A | |
| 16 | Y012Y4341 | Nipple |
| 17 | Y4SK98020 | Rim Sticker Unit (Standard) |
| Y4SK98090 | Rim Sticker Unit (Monotone) | |
| Y4SK98130 | Rim Sticker Unit (Red) | |
| Y4SK98140 | Rim Sticker Unit (Blue) | |
| Y4SK98150 | Rim Sticker Unit (Orange) | |
| Y4SK98160 | Rim Sticker Unit (Green) | |
| Y4SK98170 | Rim Sticker Unit (Sky Blue) | |
| Y4SK98180 | Rim Sticker Unit (High-Tech Grey) | |
| 18 | EWHRIMTAPERA | Rim Tape |
