シマノ スモールパーツ・補修部品 SM-BB93 スペーサー Y1P804000 SHIMANO
355
＠シマノスモールパーツ SHIMANO（シマノ）
'
| XTR Crankset FC-M9000、SM-BB93 SM-CRM90/CRM91 |  | |
| 番号 | 型番 | 商品名 |
| 01 | Y1LR13000 | Crank Arm Fixing Bolt |
| 02 | Y1PV98010 | Left Hand Crank Arm 170 mm |
| Y1PV98020 | Left Hand Crank Arm 175 mm | |
| 03 | Y1E512100 | Clamp Bolt (M6 × 15) |
| 04 | Y1GE98050 | Plate |
| 05 | Y1F316000 | Ring |
| 06 | Y1P898010 | Left Hand Adapter (B.C.1.37" x 24T) English Thread |
| 07 | Y1P804000 | Spacer (2.5 mm) |
| 08 | Y1LR98090 | Inner Cover & O-Ring |
| 09 | Y1TF21000 | O-Ring |
| 10 | Y1P898020 | Right Hand Adapter (B.C.1.37" x 24T) English Thread |
| 11 | Y1PV98102 | Gear Fixing Bolt (M7x8.5 / 4pcs.) |
| 12 | Y1PV98201 | Chainring Fixing Parts & Fixing Bolt (8pcs.) Set for Double 38-28T / 36-26T / 34-24T |
| 13 | Y1PV24000 | Chainring 24T-AS for 34-24T |
| Y1PV26000 | Chainring 26T-AT for 36-26T | |
| Y1PV28000 | Chainring 28T-AW for 38-28T | |
| 14 | Y1PV98040 | Chainring 34T-AS for 34-24T |
| Y1PV98050 | Chainring 26T-AT for 36-26T | |
| Y1PV98060 | Chainring 28T-AW for 38-28T | |
| 15 | ISMCRM90A0 | Chainring 30T (SM-CRM90) |
| ISMCRM90A2 | Chainring 32T (SM-CRM90) | |
| ISMCRM90A4 | Chainring 34T (SM-CRM90) w/Gear Spacer | |
| ISMCRM90A6 | Chainring 36T (SM-CRM90) w/Gear Spacer | |
| ISMCRM91A0 | Chainring 30T (SM-CRM91) | |
| ISMCRM91A2 | Chainring 32T (SM-CRM91) | |
| ISMCRM91A4 | Chainring 34T (SM-CRM91) | |
| ISMCRM91A6 | Chainring 36T (SM-CRM91) | |
| 16 | Y1PV98101 | Chainring Fixing Parts & Fixing Bolt (4pcs.) Set for Single 36T / 34T / 32T / 30T |
| 17 | Y1PV98030 | Gear Spacer (4pcs.) for SM-CRM90 34T / 36T Only |
