BIANCHI VIA NIRONE7 DISC SORA ビアンキ ビアニローネ ロードバイク ディスクロード アルミ
148,000
BIKE TECH SPEC
FRAME
ALLOY HYDRO-FORMING TUBING with QR
FORK
CARBON 1-1/8" DISC BRAKE FLAT MOUNT 12×100mm THRU AXLE"
COLOR
CK16/Titanium Silver Full Glossy
Serial Black/Titanium Silver Full Glossy
SIZE
47 ：適応身長目安158〜168ｃｍくらい
50 ：適応身長目安163〜173ｃｍくらい
53 ：適応身長目安168〜178ｃｍくらい
CODE
YTBJK
NOTE
※画像は見本のため、一部パーツは異なります。
スペックは予告なく変更になる場合がございます。
後輪はクイックレリーズ仕様となります。
FRAME
ALLOY HYDRO-FORMING TUBING with QR
FORK
CARBON 1-1/8" DISC BRAKE FLAT MOUNT 12×100mm THRU AXLE"
COLOR
CK16/Titanium Silver Full Glossy
Serial Black/Titanium Silver Full Glossy
SIZE
47 ：適応身長目安158〜168ｃｍくらい
50 ：適応身長目安163〜173ｃｍくらい
53 ：適応身長目安168〜178ｃｍくらい
CODE
YTBJK
NOTE
※画像は見本のため、一部パーツは異なります。
スペックは予告なく変更になる場合がございます。
後輪はクイックレリーズ仕様となります。
FRAMESET
FRAME
VIA NIRONE 7 ALL ROAD alloy, TC18, hydroforming tubing, internal cable, seatpost: 31.6mm, flat mount disc brake, OLD 135mm, QR, 40mm tire clearance, rear QR, rack & fender eyelets, downtube underside bottle cage bosses
FORK
Carbon 1-1/8, flat mount, disc brake, thru axle 12x100mm
HEADSET
FSA NO.8B / ZS4D
DRIVETRAIN
SHIFTERS
Shimano Sora ST-R3000 9sp
REAR DERAILLEUR
Shimano Sora RD-R3000 GS 9sp
FRONT DERAILLEUR
Shimano Sora FD-R3000
CRANKSET
Shimano Sora FD-R3000 50X34T 170mm
BOTTOM BRACKET
Included in the crankset
CHAIN KMC X9
PEDAL N.A.
BRAKES
BRAKES Shimano BR-RS305 Cable disc brake
ROTOR Shimano SM-RT64 rotor for disc brake center lock , S 160mm
WHEELS HUB Front: Formula CL-712 road disc , alloy 32h, center lock, J-bend, thru axle 12x100mm Rear: Formula CL-26 disc brake road, alloy sealed bearing rear hub 2SB, J-Bend 32h, 135mm*145mm QR
RIM Velomann ATD470 Alloy 6061 disc, 700c, 622x17
TIRE Vittoria Zaffiro V 32-622,700x32c
COCKPIT
STEM Velomann ST182A, Alloy 6061, raise +/ - 7°, height 38mm, Oversize, 1-1/8 , 90mm
HANDLEBAR Velomann RA35A Compact, Flat Top, alloy 6061 diam. 31,8mm, reach 80mm, drop 130mm , 400mm
GRIPS VLT-1001 w/Bianchi embossed logo; w/VLT-49 CP end plug w/o cork
SADDLE SEATPOST Velomann SP02.1 Alloy shaft AL6061, alloy head, 15mm offset, 31,6mm, 350mm
SADDLE Velomann 2302HRN
FRAME
VIA NIRONE 7 ALL ROAD alloy, TC18, hydroforming tubing, internal cable, seatpost: 31.6mm, flat mount disc brake, OLD 135mm, QR, 40mm tire clearance, rear QR, rack & fender eyelets, downtube underside bottle cage bosses
FORK
Carbon 1-1/8, flat mount, disc brake, thru axle 12x100mm
HEADSET
FSA NO.8B / ZS4D
DRIVETRAIN
SHIFTERS
Shimano Sora ST-R3000 9sp
REAR DERAILLEUR
Shimano Sora RD-R3000 GS 9sp
FRONT DERAILLEUR
Shimano Sora FD-R3000
CRANKSET
Shimano Sora FD-R3000 50X34T 170mm
BOTTOM BRACKET
Included in the crankset
CHAIN KMC X9
PEDAL N.A.
BRAKES
BRAKES Shimano BR-RS305 Cable disc brake
ROTOR Shimano SM-RT64 rotor for disc brake center lock , S 160mm
WHEELS HUB Front: Formula CL-712 road disc , alloy 32h, center lock, J-bend, thru axle 12x100mm Rear: Formula CL-26 disc brake road, alloy sealed bearing rear hub 2SB, J-Bend 32h, 135mm*145mm QR
RIM Velomann ATD470 Alloy 6061 disc, 700c, 622x17
TIRE Vittoria Zaffiro V 32-622,700x32c
COCKPIT
STEM Velomann ST182A, Alloy 6061, raise +/ - 7°, height 38mm, Oversize, 1-1/8 , 90mm
HANDLEBAR Velomann RA35A Compact, Flat Top, alloy 6061 diam. 31,8mm, reach 80mm, drop 130mm , 400mm
GRIPS VLT-1001 w/Bianchi embossed logo; w/VLT-49 CP end plug w/o cork
SADDLE SEATPOST Velomann SP02.1 Alloy shaft AL6061, alloy head, 15mm offset, 31,6mm, 350mm
SADDLE Velomann 2302HRN
