Specification Sheet (pdf)■測定値と仕様■
・製品測定値
Chassis Hole Diameter : 0.438 in.
Current, maximum : 5 A
Item Height : 23.0 mm
Item Length : 22.8 mm
Item Width : 20.1 mm
Life, minimum : ? 10,000 operations
Nominal Contact Resistance : < 50 mΩ
Nut Diameter : 11.3 mm
Temperature Rating : -10°C ~ 70°C
U.S. Thread Major Diameter : 0.375 in.
U.S. Thread Pitch : 20 tpi.
Withstand Voltage : 2,000 VDC per minute
・パッケージ情報
Packaging Dimensions : 1.286 in. × 0.775 in. × 0.94 in.
Weight (Packaging) : 0.0188 lbs.
